42x42x60mm NEMA 17 Stepper Motor 4 Wire 0.6N.M For CNC Robot

42x42x60mm NEMA 17 Stepper Motor 4 Wire 0.6N.M For CNC Robot

Brand Name:	Casun
Model Number:	42SHD0801-25BH
MOQ:	1PC
Price:	$3.14-$5
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,ISO

Step Angel:

1.8°

Holding Torque:

600mN.m

Current:

1.5A

Motor Length:

60mm

Shaft:

Milling Flat Shaft 25mm Length

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

42x42x60mm NEMA 17

60mm NEMA 17 Stepper Motor

Stepper Motor 4 Wire 0.6N.M

Product Description

42x42x60mm NEMA 17 Stepper Motor 4 Wire 0.6N.M For CNC Robot

The external dimensions of the NEMA 17 stepper motor are standardized, the structure is compact, and it is easy to install and integrate into various devices. Suitable for many automation and mechanical applications that require precise control.

Key Features

High torque and high precision
Ideal for high-tech industry and electronic industry equipment
12 years of manufacturing experience serving over 800 customers
Engineering support available within 48 hours

Appearance

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	42 mm
Number of Phase	2 Phase
Rated Current	1.5 A
Holding Torque	600 mN.m
Resistance	1.8 ohm
Inductance	3.2 mH
Rotor Inertia	102 g-cm²
Motor Weight	0.45 kg
Number of Leads	4
Connection	Bipolar

Operating Specifications

Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130°C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Available Models

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Encoder

Brake

Gearbox

Shaft
