Special Shaft Stepper Motor
Created with Pixso.

1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor For Medical Machine Robot Camera

name

1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor For Medical Machine Robot Camera

Brand Name: Casun
Model Number: 28SHD4501-K1
MOQ: 1PC
Price: $4.14-$6.98
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
120mN.m
Current:
0.67A
Motor Length:
51.5mm
Shaft:
Hollow
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

2 Phase Micro Stepper Motor

,

1.8 Degree Micro Stepper Motor

,

NEMA 11 Micro Stepper Motor

Product Description

2 Phase 1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor for Medical Machine Robot Camera



The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.



Features:

  • Professional drivetrain solution specialist

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • Professional research and development manufacturing

  • Customizations on request



Appearance



1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor For Medical Machine Robot Camera 0

Dimensions

1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor For Medical Machine Robot Camera 1

Motor Specifications

Step Angel

1.8 °

Fram Size

28 mm

Number of Phase

2 Phase

Rated Current

0.67 A

Holding Torque

120 mN.m

Resistance

9.5 ohm

Inductance

6.8 mH

Rotor Inertia

18 g-cm²

Motor weight

0.2 kg

Number of leads

4

Connection

Bipolar









Torque Curves









Download



If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
