24v DC Brushless Motor Nema 23 120w Electric Motor For Laser Machine

Name: 24v DC Brushless Motor Nema 23 120w Electric Motor For Laser Machine
Brand: GUANGZHOU FUDE ELECTRONIC TECHNOLOGY CO.,LTD
SKU: 57BL91R120-2419-21
Price: 23.00 USD
Availability: InStock

Brand Name:	Casun
Model Number:	57BL91R120-2419-21
MOQ:	1PC
Price:	$18-$28
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROSH,ISO

Speed(rpm):

1920RPM

Torque:

0.8N.m

Voltage(v):

24V

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

DC Brushless Motor Nema 23

24v DC Brushless Motor

DC Brushless Motor For Laser Machine

Product Description

24V DC Brushless Motor NEMA 23 120W Electric Motor for Laser Machine

24V Brushless Motor NEMA23 120W Electric Motor DC 24V for Laser Machine. 57BL91R120-2419-21BLDC NEMA23 with maximum speed of 1920 rpm, brushless DC 24V 120W motor with maximum torque of 0.8N.m.

Motor Type: BLDC (Brushless DC)

BLDC motors are electric motors that use a permanent magnet rotor and electronically commutated stator winding to generate motion. They offer advantages such as higher efficiency, longer lifespan, and better controllability compared to brushed DC motors.

NEMA23 Frame

NEMA (National Electrical Manufacturers Association) is a standard rating for motor frame sizes. NEMA23 refers to a specific motor size with a faceplate dimension of approximately 2.3 inches by 2.3 inches.

Key Specifications

Max Speed: 1920 rpm (revolutions per minute)
DC Voltage: 24V
Power Rating: 120W (watts)
Max Torque: 0.8 N.m (Newton meters)

Dimensions

Motor Specifications

Frame Size	57 mm
Rated Current	5A
Max Torque	0.8N.m
Resistance	1920 rpm
Inductance	2200 rpm
Rated Power	120 W
Rated Voltage	24 V
Number of Poles	4
Insulation Class	Class B

Custom Motor Solutions

If our standard motor cannot meet your needs, we can customize the motor according to your specific requirements.
