1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m

name

1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m

Brand Name: Casun
Model Number: 42SHD4079-24BH
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
320mN.m
Current:
1.33A
Motor Length:
34mm
Shaft:
Milling Flat Shaft 24mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

Stepping Motor NEMA 23 1.33A

,

Medical Equipment Stepping Motor NEMA 23

Product Description

1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment With ROHS

The 42mm stepper motor can be used in medical equipment, such as precision medical imaging equipment or surgical robots.

Excellent performance in applications that require quick start stop and frequent changes in movement direction.



Features:

  • High torque and accuracy

  • Expertise in professional research and development manufacturing

  • We are looking for dealers!

  • Professional research and development manufacturing

  • Our engineers will respond within 48 hours to provide the best solution

Appearance

1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m 0

Dimensions

1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m 1

Motor Specifications



Step Angel

1.8 °

Fram Size

42 mm

Number of Phase

2 Phase

Rated Current

1.33 A

Holding Torque

320 mN.m

Resistance

2.7 ohm

Inductance

4.2 mH

Rotor Inertia

38 g-cm²

Motor weight

0.2 kg

Number of leads

4

Connection

Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m 2 1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m 3 1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m 4 1.33A 42*42mm Stepping Motor NEMA 23 DC Motor For Medical Equipment 320mN.m 5



Please click the "Get a quote" button below to tell us your requirements.
