NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor

name

NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor

Brand Name: Casun
Model Number: P35SHD4655-13G
MOQ: 1PC
Price: $18.9-$30
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Steper Angle:
1.8degree
Phase:
2
Rated Voltage:
1.9V
Rate Current:
2A
Holding Torque:
4000mN.m
Detent Torque:
18mN.m
Ratio:
13: 1
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:38x29x18cm
Highlight:

NEMA 14 Geared Stepper Motor

,

180mN.M Geared Stepper Motor

Product Description
NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor
Product Overview

NEMA 14 Geared Stepper Motors deliver 180mN.M torque with planetary gear reduction technology. This 52mm Hybrid Stepper Motor Series offers powerful holding torque in various sizes. Use with a microstepping driver to reduce vibration and achieve higher step resolution.

  • Bipolar or unipolar versions available
  • Hybrid stepper construction
  • Available in single or double shaft versions
  • CE and RoHS approved
  • Customizations on request
Dimensions
NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor 0
Motor Specifications
SpecificationValue
Step Angle1.8°
Frame Size35 mm
Number of Phase2 Phase
Rated Current2.0 A
Holding Torque4000 mN.m
Resistance0.95 ohm
Inductance1.4 mH
Rotor Inertia28 g-cm²
Motor Weight0.5 kg
Gear Reduction Ratio13:1
ConnectionBipolar
Operating Specifications
Motor
  • Step Angle: 1.8°
  • Maximum Temperature: 80°C maximum
  • Ambient Temperature: -20°C to 50°C
  • Storage Temperature: -20°C to 100°C
  • Humidity Range: 85% or less, non-condensing
  • Magnet Wire Insulation: Class B 130°C
  • Insulation Resistance: 100M Ohm at 500 VDC
  • Dielectric Strength: 500 VDC for 1 min
Gear Box
  • Housing Material: Metal
  • Bearing at Output: Ball Bearings
  • Max. Radial Load (12mm from flange): ≤80N
  • Max. Shaft Axial Load: ≤30N
  • Radial Play of Shaft (near to Flange): ≤0.06m
  • Axial Play of Shaft: ≤0.3mm
  • Backlash at No-load: ≤1.5°
Submodels
Motor LengthLength of GearboxRatioEfficiency
26 mm
34 mm
40 mm29.1 mm3.7190%
36.8 mm13.7680%
44.6 mm5170%
Available Options
Encoder
NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor 1
Brake
NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor 2
Gearbox
NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor 3
Shaft
NEMA 14 Geared Stepper Motor 180mN.M Nema 14 Stepping Motor Planetary Gear Reducer Motor 4
Customization Services

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Get a Quote
Company Information

Location: Based in Guangdong, China, operating since 2011

Markets: Domestic Market (63%), Western Europe (12%), North America (9%), Eastern Asia (8%), Northern Europe (2%)

Staff: 51-100 people in our office

Quality Assurance
  • Always a pre-production sample before mass production
  • Always final inspection before shipment
Product Range

Stepper Motor, BLDC Motor

Why Choose Us

We are specialized in producing and selling stepper motors for more than 11 years.

Services Provided
  • Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery
  • Payment Currency: USD, CNY
  • Payment Type: T/T, L/C, D/P D/A, PayPal
  • Languages Spoken: English, Chinese, Japanese
