42x4240mm Nema 17 Stepper Motor 1.8 Degree 2 Phase 1.7A Automatic Device Stepper Motor

42x4240mm Nema 17 Stepper Motor 1.8 Degree 2 Phase 1.7A Automatic Device Stepper Motor

Brand Name:	Casun
Model Number:	42SHD4289-24
MOQ:	1PC
Price:	$3.14-$7
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Step Angel:

1.8°

Holding Torque:

400mN.m

Current:

1.7A

Rated Voltage:

3.4V

Motor Length:

40mm

Shaft:

Round Shaft 24mm Length

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

1.7A Nema 17 Stepper Motor

Automatic Device Nema 17 Stepper Motor

Product Description

42x4240mm Nema 17 Stepper Motor 1.8 Degree 2 Phase 1.7A Automatic Device Stepper Motor

The 42mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes. Use with a microstepping driver to reduce vibration and achieve higher step resolution. Choose a baseline version or request your own customized configuration.

Key Features

Bipolar or unipolar versions available

Hybrid stepper construction

Available in single or double shaft versions

CE and RoHS approved

Customizations on request

Appearance

Dimensions

Motor Specifications

Specification	Value
Step Angle	1.8°
Frame Size	40 mm
Number of Phase	2 Phase
Rated Current	1.7 A
Holding Torque	400 mN.m
Resistance	2 ohm
Inductance	3 mH
Rotor Inertia	57 g-cm²
Motor Weight	0.3 kg
Number of Leads	4
Connection	Bipolar

Operating Specifications

Parameter	Specification
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130 deg C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Available Models

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Available Options

Encoder

Brake

Gearbox

Shaft

Please click the "Get a quote" button below to tell us your requirements.

Frequently Asked Questions

Who are we?

We are based in Guangdong, China, starting from 2011. We sell to Domestic Market (63.00%), Western Europe (12.00%), North America (9.00%), Eastern Asia (8.00%), Northern Europe (2.00%), and other global markets. There are about 51-100 people in our office.

How can we guarantee quality?

Always a pre-production sample before mass production; Always final inspection before shipment.

What can you buy from us?

Stepper Motor, BLDC Motor

Why should you buy from us not from other suppliers?

We are specialized in producing and selling stepper motors for more than 11 years.

What services can we provide?

Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery;
Accepted Payment Currency: USD, CNY;
Accepted Payment Type: T/T, L/C, D/P D/A;
Language Spoken: English, Chinese, Japanese
