products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Captive Stepper Motor
Created with Pixso.

NEMA 17 Captive stroke 32mm 2.0A 42×42×34mm Stepper Motor for Precision machinery

name

NEMA 17 Captive stroke 32mm 2.0A 42×42×34mm Stepper Motor for Precision machinery

Brand Name: Casun
Model Number: 42SHD4244-C32LQ
MOQ: 1PC
Price: $26-$31
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
300mN.m
Current:
2.0A
Motor Length:
34mm
Strok:
32mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:38x29xc14m
Highlight:

42×42×34mm Captive Stepper Motor

,

2.0A Captive Stepper Motor

,

32mm Captive Stepper Motor

Product Description

Linear push rod stepper motors usually have standardized installation dimensions and are easy to install.

Linear push rod stepper motors are widely used in automation equipment, precision machinery, medical equipment, industrial robots, and other fields.



Features:

  • Bipolar or unipolar versions available

  • Established in China for 12 years and has served more than 800 customers

  • Professional drivetrain solution specialist

  • Contract-based manufacturing services are welcome

  • Every stepper motor model is adaptable to various applications



Appearance



NEMA 17 Captive stroke 32mm 2.0A 42×42×34mm Stepper Motor for Precision machinery 0

Dimensions

NEMA 17 Captive stroke 32mm 2.0A 42×42×34mm Stepper Motor for Precision machinery 1



Motor Specifications

Step Angel

1.8 °

Fram Size

34 mm

Number of Phase

2 Phase

Rated Current

2.0 A

minimal thrust

300mN.m

Resistance

4.5 ohm

Inductance

15 mH

Rotor Inertia

37 g.cm²

Motor weight

0.28 kg

Number of leads

4

Connection

Bipolar









Torque Curves













NEMA 17 Captive stroke 32mm 2.0A 42×42×34mm Stepper Motor for Precision machinery 2

Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
