Stepper Motor 60mm body 860mN.m 1.5A for 3D printers and robots

Stepper Motor 60mm body 860mN.m 1.5A for 3D printers and robots

Brand Name:	CASUN
Model Number:	42SHD0806-24B
MOQ:	1pcs-10pcs
Price:	$4.54/pcs - $6.34/pcs
Payment Terms:	L/C, D/A, T/T
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Step Angle:

1.8degree

Phase:

Rated Voltage:

5.25V

Rate Current:

1.5A

Holding Torque:

860mN.m

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

3D printers Stepper Motor

860mN.m Stepper Motor

1.5A Stepper Motor

Product Description

Stepper Motor 60mm body 860mN.m 1.5A for 3D printers and robots

The 42mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes. Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Key Features

OEM/ODM contract production capabilities
Hybrid stepper construction
Custom services available
Established in China for 12 years with over 800 customers served
Ten-year warranty for purchase confidence

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	60 mm
Number of Phase	2 Phase
Rated Current	1.5 A
Resistance	3.5 Ohm
Inductance	9 mH
Rotor Inertia	102 g-cm²
Motor Weight	0.45 kg
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20°C to 50°C

Storage Temperature: -20°C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130°C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min

Shaft Radial Play: 0.02Max. (450g-load)

Shaft Axial Play: 0.08Max. (450g-load)

Max. radial force: 28N (20mm from the flange)

Max. axial force: 10N

Customization Services

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, travel, linear travel per step, and more.

Frequently Asked Questions

1. Who are we?

We are based in Guangdong, China, starting from 2011. We serve Domestic Market (63.00%), Western Europe (12.00%), North America (9.00%), Eastern Asia (8.00%), Northern Europe (2.00%), and other global markets. Our office employs 51-100 people.

2. How can we guarantee quality?

Always provide a pre-production sample before mass production; Always conduct final inspection before shipment.

3. What can you buy from us?

Stepper Motor, BLDC Motor

4. Why should you buy from us instead of other suppliers?

We are specialized in producing and selling stepper motors for more than 11 years.

5. What services can we provide?

Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery
Accepted Payment Currency: USD, CNY
Accepted Payment Type: T/T, L/C, D/P D/A, PayPal
Languages Spoken: English, Chinese, Japanese
