Stepper Motor 48mm body 590mN.m 2.0A for Printers, engraving machines

Stepper Motor 48mm body 590mN.m 2.0A for Printers, engraving machines

Brand Name:	CASUN
Model Number:	42SHD4425-24BSH
MOQ:	1pcs-10pcs
Price:	$4.54/pcs - $6.34/pcs
Payment Terms:	L/C, D/A, T/T
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Step Angle:

1.8degree

Phase:

Rated Voltage:

3.0V

Rate Current:

2.0A

Holding Torque:

590mN.m

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

590mN.m Stepper Motor

2.0A Stepper Motor

48mm body Stepper Motor

Product Description

Stepper Motor 48mm body 590mN.m 2.0A for Printers, Engraving Machines

The 42mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes. Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Features

Incorporated modern manufacturing terminology
Removed redundant exclamation points for professional tone
Established in China for 12 years and has served more than 800 customers
Ten-year warranty and purchase with confidence

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	48 mm
Number of Phase	2 Phase
Rated Current	2.0 A
Resistance	1.5 Ohm
Inductance	3.0 mH
Rotor Inertia	82 g-cm²
Motor Weight	0.42 kg
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°
Maximum Temperature: 80°C maximum
Ambient Temperature: -20°C to 50°C
Storage Temperature: -20°C to 100°C
Humidity Range: 85% or less, non-condensing
Magnet Wire Insulation: Class B 130°C
Insulation Resistance: 100M Ohm at 500 VDC
Dielectric Strength: 500 VDC for 1 min
Shaft Radial Play: 0.02Max. (450g-load)
Shaft Axial Play: 0.08Max. (450g-load)
Max. radial force: 28N (20mm from the flange)
Max. axial force: 10N

Custom Solutions Available

If our standard motor cannot meet your needs, we can customize the motor according to your requirements.

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, travel, linear travel per step, etc.
