products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Captive Stepper Motor
Created with Pixso.

Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg At 600pps

name

Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg At 600pps

Brand Name: Casun
Model Number: B20SHD4351-C19P
MOQ: 1PC
Price: $7~$7.53
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Phase:
2
Insulation Class:
Class B
Phase Resistance:
5.1ohms
Current:
0.5A
Voltage:
2.55V
Body Length:
28 Mm
Holding Torque:
110 MN.m
Weight:
0.1 Kg
Shaft Length:
21 Mm
Packaging Details:
Carton:38x29x18cm
Highlight:

Hybrid Technology Linear Stepper Motor

,

Nema 8 Linear Stepper Motor

,

2.55V Linear Stepper Motor

Product Description

Casun Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg at 600pps

The Casun Nema 8 Linear Stepper Motor features hybrid technology, operating at 2.55V and delivering 0.8kg of force at 600pps. Ideal for compact, high-precision applications, it ensures smooth linear motion, reliability, and efficiency in automation and small-scale systems.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single- or double-shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

                    Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg At 600pps 0



Motor Specifications



Step Angel



 1.8°

Frame Size



 20 mm

Number of Phase



 2 Phase

Rated Current



 0.5 Amp

Holding Torque



 0.8 kg at 600 pps

Resistance



 5.1 ohm

Inductance



 1.5 mH

Rotor Inertia



 2 g.cm²

Motor weight



 0.1 kg

Connection



 Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130 deg C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min



Encoder







Voltage: 5 v

Output: A + A - B + B - Z + Z -



Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
20SHD0304 18 mN.m 1.8° 28 mm Round Shaft-20mm 0.6 A
20SHD0250 32 mN.m 1.8° 38 mm Round Shaft-20mm 0.6 A
20SHD0101

30 mN.m

 1.8° 42 mm Round Shaft-20mm 0.8A



Download



If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg At 600pps 1 Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg At 600pps 2 Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg At 600pps 3 Nema 8 Linear Stepper Motor Hybrid Technology 2.55V 0.8kg At 600pps 4





Please click the "Get a quote" button below to tell us your requirements.
