products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Special Shaft Stepper Motor
Created with Pixso.

Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer

name

Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer

Brand Name: Casun
Model Number: 42SHD4425-24BSH
MOQ: 5PC
Price: $5.36~$6.92
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 10000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Holding Torque:
590 MN.m
Voltage:
3V
Current:
2A
Body Length:
48mm
Weight:
0.42 Kg
Phase Resistance:
1.5 Ohm ±10% （At 20℃）
Shaft Length:
72 Mm
Phase:
2
Insulation Class:
Class B
Packaging Details:
Carton:38x29x18cm
Product Description

Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer

A high-performance Nema 17 stepper motor (42×48mm) delivering 590mN.m holding torque at 3.0V, optimized for 3D printers, CNC machines, and automation. With a 1.8° step angle, it ensures smooth, precise movements for consistent results.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

                    Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer 0



Motor Specifications



Step Angel



 1.8°

Frame Size



 48 mm

Number of Phase



 2 Phase

Rated Current



 2 Amp

Holding Torque



 590 mN.m

Resistance



 1.5 ohm

Inductance



 3 mH

Rotor Inertia



 82 g.cm²

Motor weight



 0.42 kg

Connection



 Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130 deg C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min



Encoder







Voltage: 5 v

Output: A + A - B + B - Z + Z -



Submodels



                    Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer 1



Download



If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer 2 Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer 3 Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer 4 Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer 5





Please click the "Get a quote" button below to tell us your requirements.
