DC Brushless Motor
Created with Pixso.

Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation

name

Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation

Brand Name: Casun
Model Number: 57BS94R120-2419-20GQ
MOQ: 5
Price: $46~$48
Payment Terms: D/A,T/T,L/C,D/P
Supply Ability: 10000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Holding Torque:
0.6 N.m
Voltage:
24 V DC
Current:
5 A
Body Length:
186 Mm
Weight:
2 Kg
Phase Resistance:
0.5 Ohm ±10% （At 20℃）
Shaft Length:
28 Mm
Phase:
2
Insulation Class:
Class B
Packaging Details:
Carton:38x29x18cm
Highlight:

Nema 23 BLDC motor with gearbox

,

3000RPM brushless motor for automation

,

0.6N.m DC motor with reduction gearbox

Product Description
Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation
Product Specifications
Attribute Value
Holding Torque 0.6 N.m
Voltage 24 V
Current 5 A
Body Length 186 mm
Weight 2 kg
Phase Resistance 0.5 ohm ±10% (At 20℃)
Shaft Length 28 mm
Phase 2
Insulation Class Class B
Product Description

The Casun Nema 23 BLDC Motor integrates a high-efficiency brushless DC design with a precision reduction gearbox, delivering 3000 RPM and 0.6N.m torque for robust automation performance. This compact yet powerful solution ensures reliable speed control and durability in demanding industrial applications.

Key Features
  • Bipolar or unipolar versions available
  • Hybrid stepper construction
  • Available in single or double shaft versions
  • CE and RoHS approved
  • Customizations on request
Dimensions
Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation 0
Motor Specifications
Step Angle 1.8°
Frame Size 186 mm
Number of Poles 8
Rated Current 5 Amp
Holding Torque 0.6 N.m
Resistance 0.5 ohm± 10%(At 20℃)
Inductance 1.2 mH ±20%
Rotor Inertia 38 g.cm²
Motor weight 0.2kg
Connection Bipolar
Operating Specifications
Motor
Step Angle 1.8°
Maximum Temperature 80°C maximum
Ambient Temperature -20°C to 50°C
Storage Temperature -20°C to 100°C
Humidity Range 85% or less, non-condensing
Magnet Wire Insulation Class B 130°C
Insulation Resistance 100M Ohm at 500 VDC
Dielectric Strength 500 VDC for 1 min
Encoder
Voltage 5 V
Output A + A - B + B - Z + Z -
Submodels
Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation 1Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements.

Customized content includes but is not limited to:

  • Special shafts
  • Winding parameters
  • Installation dimensions
  • Lead wires with special requirements
  • Connectors
Available Options
Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation 2 Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation 3 Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation 4 Casun Nema 23 BLDC Motor with Reduction Gearbox 3000RPM 0.6N.m Motor for Automation 5
Please click the "Get a quote" button below to tell us your requirements.
Get a Quote
