1.5A 800mN.M NEMA 24 Geared Stepper Motor For CNC Machine 60mm

1.5A 800mN.M NEMA 24 Geared Stepper Motor For CNC Machine 60mm

Brand Name:	Casun
Model Number:	60SHD
MOQ:	1PC
Price:	$3.14-$5
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,ISO

Step Angel:

1.2°

Holding Torque:

800mN.m

Current:

1.5A

Motor Length:

58mm

Shaft:

Round Shaft 24mm Length

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

1.5A 800mN.M NEMA 24

1.5A NEMA 24 Geared Stepper Motor

800mN.M Stepper Motor For CNC Machine

Product Description

1.5A 800mN.M NEMA 24 Geared Stepper Motor For CNC Machine 60mm

The 60mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes. Use with a microstepping driver to reduce vibration and achieve higher step resolution. Choose a baseline version or request your own customized configuration.

Key Features

High torque and high precision
For high-tech industry and electronic industry equipment
Available in single or double shaft versions
Professional research and development manufacturing

Appearance

Motor Specifications

Step Angle	1.8°
Frame Size	60 mm
Number of Phase	2 Phase
Rated Current	3.0 A
Holding Torque	3.5N.m
Resistance	0.55 ohm
Inductance	1.7 mH
Motor Weight	0.98 kg
Number of Leads	4
Connection	Bipolar

Operating Specifications

Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130 deg C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Submodels

Model	Holding Torque (mN.m)	Rated Current (A)	Resistance per phase (Ω)	Inductance per phase (mH)	Detent torque (mN.m)	Rotor inertia (g.cm²)	Lead wire (No.)	Motor length (mm)
60SHD4201	650	0.6	15	20	50	280	4	45
60SHD4401	1500	2.8	1	3.3	70	450	4	56
60SHD4601	3200	4.2	0.75	3.7	120	580	4	86
60SHD6602	2500	3	1.55	3.7	120	580	4	-

Customization Available

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Available Options

Encoder

Brake

Gearbox

Shaft

Our engineers will be in touch within 48 hours to provide the best solution for your application.
