GUANGZHOU FUDE ELECTRONIC TECHNOLOGY CO.,LTD Company Profile
products
Home > products > Geared Stepper Motor > NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle
NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle
NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle
NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle
NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle
NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle
NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle

NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: 17HS15-1684D-HG10

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $20-$23

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

40mm body Planetary Gear Stepping Motor

,

Intelligent Vehicle Planetary Gear Stepping Motor

,

NEMA 17 Planetary Gear Stepping Motor

Key Words:
Geared Stepper Motor
Voltage:
2.8V DC
Weight:
0.9KG
Step Angle(degrees):
1.8 Degree
Ratio:
10:1
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Key Words:
Geared Stepper Motor
Voltage:
2.8V DC
Weight:
0.9KG
Step Angle(degrees):
1.8 Degree
Ratio:
10:1
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

Deceleration stepper motors have high reliability due to their relatively simple mechanical structure and low maintenance costs.

Widely used in industrial automation, mechanical equipment, medical equipment and other fields.



Features:

  • Bipolar or unipolar versions available

  • Our manufacturing process is backed by professional research and development

  • Experts in drivetrain solutions

  • CE and RoHS approved

  • Customizations on request

Dimensions

NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle 0







Motor Specifications



Step Angel



1.8 °

Fram Size



42mm

Number of Phase



2 Phase

Rated Current



1.68Amp

Holding Torque



390mN.m

Resistance



1.65 ohm

Inductance



3.2 mH

Rotor Inertia



57g-cm²

Motor weight



0.9kg

Gear Reduction Ratio





10:1

Connection



Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min



Gear Box



Housing Material:Metal
Bearing at Output:Ball Bearings
Max.Radial Load(12mm from flange):≤80N
Max.Shaft Axial Load:≤30N
Radial Play of Shaft (near to Flange):≤0.06mm
Axial Play of Shaft:≤0.3mm
Backlash at No-load:1.5°











Torque Curves







Submodels

Motor Length Length of Gearbox Raio Efficiency
34 mm

40 mm

48 mm

60 mm		 27.2 mm 3.71 90%
5.18
35 mm 13.76 80%
19.2
26.8
42.7 mm 51 70%
71
99.5
139


Download





If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle 1 NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle 2 NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle 3 NEMA 17 Ratio 10/1 Planetary Gear Stepping Motor 40mm Body For Intelligent Vehicle 4





Please click the "Get  a quote" button below to tell us your requirements.
