Home > products > Hybrid Stepper Motor > 15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment
15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment
15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment
15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment
15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment
15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment

15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROSH,ISO

Model Number: 20SHD0001-20

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $5.94-$8.6

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
High Light:

0.6A NEMA 8 Stepper Motor

,

15mNm NEMA 8 Stepper Motor

,

15mNm 0.6A Mini Stepping Motor

Step Angel:
1.8°
Holding Torque:
15mN.m
Current:
0.6A
Motor Length:
30mm
Shaft:
Round Shaft 20mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angel:
1.8°
Holding Torque:
15mN.m
Current:
0.6A
Motor Length:
30mm
Shaft:
Round Shaft 20mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

The NEMA 8 stepper motor is used to control various stages of the packaging process, such as filling, sealing, and packaging.

High precision, compact size, high torque retention, and fast response speed.



Motor Specifications

Step Angel

1.8 °

Fram Size

20 mm

Number of Phase

2 Phase

Rated Current

0.6 A

Holding Torque

15 mN.m

Resistance

6.5 ohm

Inductance

1.7 mH

Rotor Inertia

2 g-cm²

Motor weight

0.06 kg

Number of leads

4

Connection

Bipolar





Appearance



15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment 0

Dimensions

15mNm 0.6A NEMA 8 Stepper Motor Mini Stepping Motor For Medical Equipment 1



Torque Curves



















Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
