550mN.M 3.0V DC Nema 17 Hybrid Stepper Motor 42x42x48mm

550mN.M 3.0V DC Nema 17 Hybrid Stepper Motor 42x42x48mm

Brand Name:	Casun
Model Number:	42SHD0437-24BH
MOQ:	1PC
Price:	$3.14-$5
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROSH,ISO

Step Angel:

1.8°

Holding Torque:

550mN.m

Current:

1.68A

Motor Length:

48mm

Shaft:

Milling Flat Shaft 24mm Length

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

Nema 17 Hybrid Stepper Motor

550mN.M Hybrid Stepper Motor

3.0V Hybrid Stepper Motor

Product Description

550mN.M 3.0V DC Nema 17 Hybrid Stepper Motor 42x42x48mm

Casun Stepper motor 550mN.m 3.0V DC Nema 17 Hybrid Stepper Motor 42x42x48mm with factory price.

Model 42SHD0437: 1.8 Degree 2 Phase 3.0V DC Nema 17 Hybrid Stepper Motor 42×42×48mm for Stage Lighting

The 42mm Hybrid Stepper Motor Series is a versatile and powerful option for various applications. The ability to reduce vibration and achieve higher step resolution through microstepping drivers provides greater precision and control. Custom configurations are available to meet specific application requirements.

Features

Bipolar or unipolar versions available

For high-tech industry and electronic industry equipment

Available in single or double shaft versions

Multiple international certifications

Professional research and development manufacturing

Appearance

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	42 mm
Number of Phase	2 Phase
Rated Current	1.68 A
Holding Torque	550 mN.m
Resistance	1.8 ohm
Inductance	4.5 mH
Rotor Inertia	72 g-cm²
Motor Weight	0.38 kg
Number of Leads	4
Connection	Bipolar

Operating Specifications

Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130°C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Encoder

Brake

Gearbox

Shaft

Please click the button below to tell us your requirements

Get a quote
