Home > products > Hybrid Stepper Motor > 2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof
2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof
2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof
2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof
2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof

2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: 57SHD4228-21H

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $21.54-$24.94

Packaging Details: Carton:38x29x18cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

2.5Amp Casun Stepper Motor

,

Waterproof Casun Stepper Motor

Color:
Black
Current / Phase:
2.5Amp
Holding Torque:
1.2N.m
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Color:
Black
Current / Phase:
2.5Amp
Holding Torque:
1.2N.m
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof Stepper Motor



The Nema23 57MMX57MM Hybrid Open Loop Stepper Motor is a powerful and reliable option for anyone looking for a stepper motor solution for their CNC or SMT machine.
However, users should be aware that the open-loop design may be less precise than the closed-loop version, so it may not be suitable for all applications.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof 0







Motor Specifications



Step Angel



1.8 °

Fram Size



57 mm

Number of Phase



2 Phase

Rated Current



2.5 Amp

Holding Torque



1.1N.m

Resistance



1.15hm

Inductance



3.3mH

Rotor Inertia



220g-cm²

Motor weight



0.6 2kg















Operating Specifications



Motor



Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min















Torque Curves









Submodels

Model Holding Torque Step Angle Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A

Download





We have the ability to customize motor features such as shafts, winding parameters, installation dimensions, lead wires, and connectors can help to ensure that the motor is a perfect fit for the customer's application. This can lead to improved efficiency, increased reliability, and reduced downtime.



Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof 1 2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof 2 2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof 3 2.5Amp Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof 4





Please click the "Get  a quote" button below to tell us your requirements.
