Home > products > Hybrid Stepper Motor > 98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A
98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A
98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A
98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A
98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A
98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A
98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A
98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A

98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: FP86SHC3201-32BH

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $9.49-$14

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
High Light:

98mm Micro Stepper Motor

,

NEMA 34 Micro Stepper Motor

,

Micro Stepper Motor 3 Phase

Step Angle:
1.2°
Number Of Phase:
3
Rated Current:
3.5A
Body:
98mm
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angle:
1.2°
Number Of Phase:
3
Rated Current:
3.5A
Body:
98mm
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A With CE RoHs

The NEMA 34 waterproof stepper motor adopts special sealing technology and waterproof design.

In hydraulic and pneumatic equipment, it is usually necessary to use motors with good sealing performance



Features:

  • Bipolar or unipolar versions available

  • We specialize in providing customized services

  • Specializing in delivering personalized services is our area of expertise

  • Accept contract manufacturing

  • We provide a ten-year warranty for your purchase, ensuring confidence

Dimensions

98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A 0







Motor Specifications

Step Angel



1.2 °

Fram Size



86 mm

Number of Phase



3 Phase

Rated Current



3.5A

Holding Torque



4.0N.m

Resistance



3.9ohm

Inductance



22.2mH

Rotor Inertia



1700 g-cm²

Motor weight



2.9 kg

Number of leads



4

Connection



Bipolar







Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min









Torque Curves







Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
86SHD4003-32 4.0N.m 1.8° 69mm Key Shaft-32mm 4.0A
86SHD4101-32 4.5N.m 1.8° 76mm Key Shaft-32mm 4.0A
86SHD4201-37 5.6N.m 1.8° 98mm Key Shaft-37mm 4.0A
86SHD4314-37 6.8N.m 1.8° 112mm Key Shaft-37mm 5.0A
86SHD4404-37 8.0N.m 1.8° 127mm Key Shaft-37mm 5.0A
86SHD4505-37 12.0N.m 1.8° 150mm Key Shaft-37mm 5.5A



Download





If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A 1 98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A 2 98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A 3 98mm Micro Stepper Motor 3 Phase 1.2 Degree NEMA 34 2.0N.M 2.5A 4





Please click the "Get  a quote" button below to tell us your requirements.
