Nema 6 Micro Stepper Motor 5.8mN.M Step Motor For Video Conferencing Machine

Nema 6 Micro Stepper Motor 5.8mN.M Step Motor For Video Conferencing Machine

Brand Name:	Casun
Model Number:	14SHD4001-15B
MOQ:	1PC
Price:	$20-$25
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROSH,ISO

Step Angel:

1.8°

Holding Torque:

5.8mN.m

Current:

0.3A

Motor Length:

30mm

Shaft:

Round Shaft 15mm Length

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

Nema 6 Micro Stepper Motor

5.8mN.M Micro Stepper Motor

Product Description

Nema6 14x14x30mm 0.3A Casun Stepper Motor Nema 6 Mini Stepper Motor For video conferencing machine.

Motor Specifications

NEMA 6 form factor: NEMA 6 refers to the motor's frame size. It indicates the physical dimensions and mounting specifications of the motor. In this case, the motor has a 14x14x30mm size, which describes its width, height, and length.

Current rating: The motor has a current rating of 0.3A (Amperes). The current rating indicates the amount of electrical current required to operate the motor effectively.

Application: The motor is intended for use in a video conferencing machine. Stepper motors are commonly used in various applications that require precise control of motion, such as robotics, automation, 3D printers, and motion control systems.

Step Angel	1.8 °
Fram Size	14 mm
Number of Phase	2 Phase
Rated Current	0.3 A
Holding Torque	5.8 mN.m
Resistance	3.8 ohm
Inductance	21mH
Rotor Inertia	2g-cm²
Motor weight	0.08 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
