600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment

name

600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment

Brand Name: Casun
Model Number: 42SHB0801-20B
MOQ: 1PC
Price: $5.98-$7.9
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROSH,ISO
Step Angel:
0.9 Degree
Holding Torque:
600mN.m
Current:
1.5A
Motor Length:
60mm
Shaft:
Milling Flat Shaft 20mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

1.5A Hybrid Stepper Motor

,

NEMA 17 Hybrid Stepper Motor

,

0.9 Degree Hybrid Stepper Motor

Product Description
600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment
Product Overview

Hybrid Stepper Motor NEMA17 featuring 0.9 degree step angle and 600mN.M holding torque, designed specifically for automation equipment applications. This 42x42x60mm motor delivers reliable performance with factory-direct pricing.

Key Specifications
  • Step Angle: 0.9° - Angular increment per step for precise positioning
  • Phase: 2 Phase - Dual winding configuration for optimized sequencing
  • Voltage: 5.45V DC - Recommended operating voltage for optimal performance
  • Size: 42×42×60mm - NEMA 17 standard with extended length
  • Holding Torque: 600mN.m - Maximum static torque capacity
Product Features
  • Bipolar or unipolar versions available
  • Ideal for high-tech and electronic industry equipment
  • Available in single or double shaft versions
  • Multiple international certifications
  • Professional research and development manufacturing
Product Appearance
600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment 0
Motor Dimensions
600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment 1
Motor Specifications
Parameter Specification
Step Angle 0.9°
Frame Size 42 mm
Number of Phase 2 Phase
Rated Current 1.5 A
Holding Torque 600 mN.m
Resistance 1.8 ohm
Inductance 4.5 mH
Rotor Inertia 72 g-cm²
Motor Weight 0.46 kg
Number of Leads 4
Connection Bipolar
Operating Specifications
Parameter Specification
Step Angle 1.8°
Maximum Temperature 80°C maximum
Ambient Temperature -20°C to 50°C
Storage Temperature -20°C to 100°C
Humidity Range 85% or less, non-condensing
Magnet Wire Insulation Class B 130°C
Insulation Resistance 100M Ohm at 500 VDC
Dielectric Strength 500 VDC for 1 min
Available Submodels
Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A
Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements.

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Encoder
600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment 2
Brake
600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment 3
Gearbox
600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment 4
Shaft
600mN.M 1.5A Hybrid Stepper Motor NEMA 17 0.9 Degree For Automation Equipment 5

Please click the "Get a quote" button below to tell us your requirements.
