1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO

Place of Origin CHINA
Brand Name Casun
Certification CE,ROHS,ISO
Model Number 57SHD4408-21B
Product Details
Step Angel:
1.8°
Holding Torque:
1.0N.m
Current:
2.5A
Motor Length:
54mm
Shaft:
Milling Flat Shaft 21mm Length
High Light:

54mm Length NEMA 23 Stepper Motor

,

2 Phase NEMA 23 Stepper Motor

Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
$3.14-$5
Packaging Details
Carton:36x29x14cm
Delivery Time
7-15 days
Payment Terms
D/A, T/T, L/C, D/P
Supply Ability
40000+PCS+Month
Product Description

1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO



By adjusting the pulse frequency sent to the motor, the speed of the stepper motor can be precisely controlled.

3D printers, CNC machine tools, automated production lines, and industrial robots.



Features:

  • Focused on drivetrain solutions

  • Our products are designed for high torque and precision

  • With 12 years of experience in China, we have served more than 800 customers

  • We provide customized services and welcome contract manufacturing

  • In search of partners!

Motor Specifications

Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

2 Phase

Rated Current

2.5 A

Holding Torque

1.0 N.m

Resistance

1.2 ohm

Inductance

4.1 mH

Rotor Inertia

260 g-cm²

Motor weight

0.6 kg

Number of leads

4

Connection

Bipolar



Appearance

1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO 0

Dimensions

1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft

1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO 2 1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO 3 1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO 4 1.8 Degre 2 Phase 54mm Length NEMA 23 Stepper Motor With CE ROHS ISO 5
