products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Hybrid Stepper Motor
Created with Pixso.

STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO

name

STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO

Brand Name: Casun
Model Number: 57SHD0221-21B
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
500mN.m
Current:
0.5A
Motor Length:
50mm
Shaft:
Milling Flat Shaft 21mm Length
Shaft Diameter:
6.35mm
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

Robot NEMA 23 Stepper Motor

,

0.5N.m NEMA 23 Stepper Motor

,

57×57×50mm NEMA 23 Stepper Motor

Product Description

Stepper motors are suitable for various environments, such as high temperature, low temperature, humidity, dust, etc., and have good adaptability.

In the field of robotics, stepper motors can achieve precise motion control, improving the flexibility and stability of robots.



Features:

  • High torque and high precision

  • accept contract manufacturing

  • We have been operating in China for 12 years, serving over 800 customers

  • Specialists in professional drivetrain solutions

  • Professional research and development manufacturing





Motor Specifications



Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

2 Phase

Rated Current

0.5 A

Holding Torque

500 mN.m

Resistance

24 ohm

Inductance

20 mH

Rotor Inertia

220 g-cm²

Motor weight

0.55 kg

Number of leads

4

Connection

Bipolar

Appearance

STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO 0

Dimensions

STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO 2 STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO 3 STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO 4 STEPPER MOTOR NEMA 23 For Robot 0.5N.m 57×57×50mm With ISO 5



Please click the "Get a quote" button below to tell us your requirements.



Tags:

2 Phase Bipolar Stepper Motor

Nema 6 Bipolar Stepper Motor

Robot NEMA 23 Stepper Motor
