NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine

name

NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine

Brand Name: Casun
Model Number: 57SHD0914-21BH
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
2200mN.m
Current:
2.8A
Motor Length:
82.8mm
Shaft:
Milling Flat Shaft 21mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

Textile Machine NEMA 23 Stepper Motor

,

High Torque NEMA 23 Stepper Motor

,

83mm NEMA 23 Stepper Motor

Product Description

The stepper motor does not experience speed fluctuations at low speeds, ensuring the stability and reliability of the system.

NEMA 23 stepper motors typically have high torque output and can meet the load requirements of many applications.

Features:

  • High accuracy and torque

  • We specialize in custom services and contract manufacturing

  • Boasting high torque and precision

  • Dealers wanted!

  • Established in China for 12 years, serving over 800 customers





Motor Specifications

Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

4 Phase

Rated Current

2.8 A

Holding Torque

2200 mN.m

Resistance

1.1 ohm

Inductance

2.6 mH

Rotor Inertia

520 g-cm²

Motor weight

1.3 kg

Number of leads

4

Connection

Bipolar

Appearance

NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine 0

Dimensions

NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine 2 NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine 3 NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine 4 NEMA 23 Two-phase 1.8° 57 STEPPER MOTOR 83mm Body High Torque 2.8A For Textile Machine 5



Please click the "Get a quote" button below to tell us your requirements.
