28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications

28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications

28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications

Brand Name: Casun
Model Number: 28SHD4202-20L-0
MOQ: 1pc
Price: $6.5-11
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
60mN.m
Current:
0.67A
Motor Length:
28MM
Shaft:
Screw Shaft 28.2mm Length
Phase:
2
Rated Voltage:
3.8V
Detent Torque:
5mN.m
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:210x190x170
Highlight:

DC Power Mini Stepper Motor

,

2-Phase Hybrid Stepper Motor

,

Hybrid Micro Stepper Motor

Product Description
NEMA 11 Hybrid Micro Stepper Motor
28×28×32mm NEMA 11 hybrid micro stepper motor with 1.8° step angle, 0.67A rated current, and 0.06N.m holding torque. CE certified for quality assurance.
Key Features
  • Compact 28×28mm NEMA 11 frame size ideal for space-constrained precision equipment
  • Perfect for portable devices and small automation applications
  • Low inertia rotor enables fast start/stop cycles and responsive performance
  • Single or dual-axis output with easy installation of couplings and encoders
  • Available in 4-wire (bipolar) or 6-wire (unipolar) configurations
  • RoHS and CE compliant for environmental and safety standards
  • Expert engineering support available within 48 hours
Motor Dimensions
28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications 0
Motor Specifications
Step Angle 1.8°
Frame Size 28 mm
Number of Phase 2 Phase
Rated Current 0.67 A
Holding Torque 60 mN.m
Resistance 5.6 ohm
Inductance 3.4 mH
Rotor Inertia 9 g-cm²
Motor Weight 0.12 kg
Number of Leads 4
Connection Bipolar
Operating Specifications
Maximum Temperature 80°C maximum
Ambient Temperature -20°C to 50°C
Storage Temperature -20°C to 100°C
Humidity Range 85% or less, non-condensing
Magnet Wire Insulation Class B 130°C
Insulation Resistance 100M Ohm at 500 VDC
Dielectric Strength 500 VDC for 1 min
Shaft Radial Play 0.02Max. (450g-load)
Shaft Axial Play 0.08Max. (450g-load)
Max. Radial Force 28N (20mm from the flange)
Max. Axial Force 10N
Available Options
28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications 1
Encoder
28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications 2
Brake
28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications 3
Gearbox
28*28*32 Mini NEMA 11 Hybrid Micro Stepper Motor 1.8 Degree 2-Phase Driver DC Power With CE Certifications 4
Shaft
Customization Services
If our standard motor cannot meet your requirements, we can customize the motor according to your specific needs. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, and more.
Frequently Asked Questions
Who are we?
We are based in Guangdong, China, established in 2011. Our primary markets include Domestic Market (63%), Western Europe (12%), North America (9%), and Eastern Asia (8%). Our office employs 51-100 professionals dedicated to motor manufacturing.
How can we guarantee quality?
We maintain strict quality control through pre-production samples and final inspection before shipment to ensure every motor meets our high standards.
What can you buy from us?
We specialize in Stepper Motors and BLDC Motors for various industrial applications.
Why should you buy from us instead of other suppliers?
With over 11 years of specialized experience in stepper motor production and sales, we offer proven expertise and reliable performance.
What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery
Accepted Payment Currency: USD, CNY
Accepted Payment Type: T/T, L/C, D/P D/A, PayPal
Languages Spoken: English, Chinese, Japanese
