Home > products > Hybrid Stepper Motor > 2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor
2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor
2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor
2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor
2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor

2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROSH,ISO

Model Number: 42SHD0001-24

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $3.14-$5

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

0.4A NEMA 17 Stepper Motor

,

12V NEMA 17 Stepper Motor

,

34mm NEMA 17 Stepper Motor

Step Angel:
1.8°
Holding Torque:
260mN.m
Current:
0.4A
Motor Length:
34mm
Shaft:
Round Shaft 24mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angel:
1.8°
Holding Torque:
260mN.m
Current:
0.4A
Motor Length:
34mm
Shaft:
Round Shaft 24mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

Different performance requirements can be achieved through different driving methods, such as full step, half step, and micro step.

By adjusting the frequency of the pulse signal, the motor speed can be precisely controlled to achieve precise speed adjustment.



Features:

  • Established in China for 12 years, serving over 800 clients

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • We are open to contract manufacturing

  • Customizations on request

Appearance

2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor 0

Dimensions 2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor 1



Motor Specifications



Step Angel

1.8 °

Fram Size

42 mm

Number of Phase

2 Phase

Rated Current

0.4 A

Holding Torque

260 mN.m

Resistance

30 ohm

Inductance

37 mH

Rotor Inertia

38 g-cm²

Motor weight

0.2 kg

Number of leads

4

Connection

Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor 2 2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor 3 2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor 4 2 Phase NEMA 17 1.8 deg 26N.cm 0.4A 12V DC 34mm 4 Wires Bipolar Stepper Motor 5



Please click the "Get a quote" button below to tell us your requirements.
